Speed Reducer Input Connection Type C-Face Maximum Output Speed 61 RPM Motor Frame Designation 42CZ/48 Base to Center 3.33 in Gear Ratio 28.13 1 Rotation - Maximum Input Horsepower 0.25 hp Maximum Output Torque 242 in-lb Overhung Load Capacity 175 ft-lb Mounting Orientation Any Angle Overall Height 4.75 in Application Speed Reducer Bearing Type Ball Maximum Input Speed 1 725 RPM Gear Material Steel
