Speed Reducer Input Connection Type C-Face Gear Type Worm Output Shaft Type Round Maximum Output Speed 58 RPM Motor Frame Designation 180TC/210C Worm Center Distance 5.15 in Base to Center 5.31 in Gear Ratio 30 1 Rotation CW/CCW Maximum Input Horsepower 7.3 hp Maximum Output Torque 6964 in-lb Overhung Load Capacity 2 200 ft-lb Mounting Orientation Any Angle Housing Material Cast Iron Bearing Type Tapered Roller Gear Material Hardened and Ground Steel
